The Benefits:

  • Single use
  • cGMP compliant
  • Easy installation
  • Small surface area requirements
  • 1000 mL reactor body can process up to 100 L of resuspended cells in under 8h
  • Reliable precise control of lysis time
  • Efficient neutralisation and impurities precipitation (RNA, gDNA) by patented flow mixer
  • Can be gamma irradiated
Catalog no. BIA-ALK1000-9-LR-E

The Lysis Reactor is a single-use component to use in combination with the In-line Lysis System’s Tower. Together they form fully automated in-line lysis system with a closed single-use loop for process development (PD) up to pilot scale. The Lysis Reactor is a single use component with simple installation, requires little countertop space and provides a clean and simple alternative to larger batch lysis processes allowing user to use it as a plug and play combination. It consists of the main reactor body with a fixed volume of 1000 mL, 5 inlet paths (4 solutions and one air) and an outlet path.

Operating Flow Rate: 40 -500 mL/min

Volume: 1000 mL

Compatible with: In-line Lysis Tower 1000,  In-line Lysis Tower 1000 cGMP, In-line Lysis Tower 5000 and In-line Lysis Tower 5000 cGMP
